Flatwork Ironer High Pressure Drying and Pressing Machine.Calendering Machine

Flatwork Ironer High Pressure Drying and Pressing Machine.Calendering Machine Specification

Product Type
Garment Machinery

Material
stainless steel

Machinery Type
Other

Capacity
high speed Kg/hr

Voltage
Single & Triple phase Volt (v)

Power
5.5 kw/p/h Watt (w)

Dimension (L*W*H)
4000x1200x1200 Millimeter (mm)

Weight
1650 Kilograms (kg)

Color
Grey

Warranty
One Year

Flatwork Ironer High Pressure Drying and Pressing Machine.Calendering Machine Trade Information

Minimum Order Quantity
1 Piece

FOB Port
.

Supply Ability
Piece

Delivery Time
20 Days

Sample Available
Yes

Sample Policy
Free samples are available

Packaging Details
wooden packing

Main Export Market(s)
Africa

Main Domestic Market
All India

Certifications
ISO, CE, MSME,GMP, IAF, DAC OHSAS

Flatwork Ironer High Pressure Drying and Pressing Machine.Calendering Machine About

FEATURES

It is with speed adjusting motor and LS speed controller with the large controlling range.
It is derived by gears, reduced the twitter and noise generated by sprocket.
Conveyor belt is of exclusive brand which is with high temperature resistance and any -static.
For bed sheets, quilts, tablecloth, towel, curtain, bath towel etc.
Large diameter (800mm) roller drum, stainless steel, surface is Smooth.
Frame and auxiliary, high-quality steel carbon structures, strong and Durable.
Variable frequency, variable speed, according to fabric, moisture, steam supply, etc.
Simple control with Start/Stop button.
Sealed rotary joints prevent leakage, safety and reliability, save energy.
Three-phase electrical system, overload protection, voltage and short circuit protection, emergency stop swift
The fence and travel switch in the input part, reduce fatigue, misuse and the risk.

Technical specification

Model - AG-2000, AG-3000, AG- 3300
Length of ironing roller (mm) - 2000, 3000, 3300
Diameter of ironing roller (mm) - 800
Rotate speed of barrel (rpm) - <4
Speed of ironing (m/min) - <10
Pressure of steam (Mpa) - 0.4-0.6
Power of electrical (kw) - 21, 28, 29
Electric heating power (kw) - 0.75, 1
External dimension (mm) - 4200x1200x1200, 4200x1200x1290, 4200x1200x1290
Machine weight (kg) - 1650, 2000, 2200

Product details

Country of Origin	Made in India
Brand	AURA
Capacity	Fully automatic Machine
Power Consumption	14 Kw
Machine Type	Fully Automatic
Crated Size	8000mm
Crated Wt	2200 kg
Dimension	4200x1200x1290
Electric Heating	0.75 kw
Model	AG-2000
Net Wt	1650 kg
Roller Dia Padded	800 mm
