Shirt Folding Table

Shirt Folding Table About

Features

• Pneumatically operated system that works like a robot and assists to press & fold jackets perfectly
• Gives much high productivity and quality
• Adjustable neck mould for different neck sizes and shapes
• Consists of aluminum gravity die casting disc supporting 5 CNC machined moulds with synchronized indexing and locking mechanism
• Automatic movement of stainless steel back plate, aided by pneumatic cylinder, ensures that the center of the neck/collar perfectly aligned with the buttons
• Button guard helps to place button in center line for giving a balanced fold
• Collar and lapel forming function to enhance their finish and shape
• Equipped with high quality and accurate thermostat
• Aluminum casted heaters
• Ergonomically designed with elegant look
• Two models available: automatic and manual
• Technical specification
• Model - AG-203/SF- Advantage ,   AG-203/SF - Premium, AG-203/SF - Ultra - Premium
• Dimension (in mm) - 1410x760x800,   1410x760x800,  2820x760x800
• Working Area (in mm)  - 1410x760,  1410x760,  1410x 760
• voltage - 220 v 1 ph
• Power Consumption - 09 kw,    0.9 kw,   1.2 kw
• Features - 1. manual     2. pneumatic connection with single collar dye     3. pneumatic  connection with five collar dye
